ACP Waterjet provides nationwide water jet & Laser cutting services. With a state-of-the-art facility dedicated  to Water Jet Cut, Bend & Laser Cutting located in Woburn, Massachusetts, ACP Waterjet offers cutting capabilities of virtually any material.

We specialize in meeting today’s demanding deadlines. Our personal attention to detail provides customers with consistent quality Cutting & Bending Services at the most competitive prices.

Any size projects are welcomed. From design to fabrication Waterjet or Laser Cutting is the popular choice for small and large productions runs.  Contact us today to discuss your next Project.

Why Waterjet?

No Heat Affected Zone
Waterjet Cut up to 6.00″ thick
Minimum to no Burr
High Precision achievable
Efficient use of material

What Materials Can We Cut?

All types of Metals
All types of Plastic
Ceramics
G10, Carbon Fiber, Kevlar.
Foam, Rubber, Gasket Materials

Why Laser?

Highly accurate cuts
Superb edge quality
Up to 0.5″ in Steel
Up to 0.25″ in Stainless
Up to 0.187 in Aluminum

Laser Cutting

  • Laser Cutting will cut Aluminum, Stainless, Nickel Alloys, Titanium & Steel.
  • Aluminum up to 0.187” thick, Steel up to 0.625” thick & Stainless up to 0.250” thick.
  • Heat is generated on the cutting process
  • Minimum thickness = 0.005” thick
  • Maximum thickness = 0.625” thick
  • Minimum part size = 0.500” x 0.500”
  • Maximum part size = 59.50” x 119.50”
  • Hole Sizes = Minimum hole size is based on the thickness of the material being cut. Its typically a one to one proportion. For example, a 0.125” thick material requires a minimum hole size of 0.125”
  • Typical tolerances:
  • Holes +/-0.005”
  • Hole Location +/-0.005”
  • Profile +/-0.010”
  • Minimum Part spacing is 0.200” between parts and a 0.500” space all around the sheet is required to allow us to clamp material to Laser table. Thicker materials will require more space.
  • Laser cutting will leave a sharp edge and cut will have a Shiny look with some striations which will vary depending on Material being cut and Assist gas used.
  • If your parts don’t fit this guideline, feel free to contact us to discuss your project.

Waterjet Cutting

  • Waterjet Cutting will cut Most Materials with the exception of Glass
  • No Heat is generated on the cutting process
  • Minimum thickness = 0.005” thick
  • Maximum thickness = 7” thick
  • Minimum part size = 0.500” x 0.500”
  • Maximum part size = 71.50” x 143.50”
  • Minimum hole size = 0.063” for Most Materials
  • Minimum hole size for Composites is 0.125”
  • Typical tolerances:
  • Holes +/-0.005”
  • Hole Location +/-0.005”
  • Profile +/-0.010”
  • Minimum Part spacing is 0.200” between parts and a 0.500” space all around the sheet is required to allow us to clamp material to waterjet table. Thicker materials will require more space.
  • Waterjet cutting will leave a sharp edge and cut will have a sandblasted look with some striations which will vary depending on cutting speed.
  • If your parts don’t fit this guideline, feel free to contact us to discuss your project.

Bending

  • Our Bending Machines will do Most Material with the exception of PLASTIC.
  • Part Maximum Length = 120”
  • Ideal inside radius to be same as material thickness. Example: For 0.125” thick Material, ideal inside radius will be 0.125”.
  • Minimum thickness = 0.020” thick
  • Maximum thickness = 0.500” thick
  • Minimum part size = 1.000” x 1.000”
  • Holes too close to bends might get deformed on the bending process.
  • Typical tolerances:
  • Part Size +/-0.010”
  • Angle +/-1 Degree
  • Parts might have die marks after bending. Please inform us if parts are cosmetic.
  • If your parts don’t fit this guideline, feel free to contact us to discuss your project.

Capabilities

Waterjets:

72″ x 144″ Mitsubishi MWX-3

72″ x 144″ Mitsubishi MWX-4 with taper control head

Laser:

60″ x 120″ Trumpf 1030 2000 Watt CO2 Laser Cutting Machine.

Press Brake:

110 Ton x 120” Trumpf Trubend 3100 CNC Press Brake

Materials We Stock:

ACP Waterjet stock the most common used materials like Aluminum, Stainless Steel and Mild Steel Sheets and Plates.

    5052-H32, 3003, 2024 and 6061-T6 Aluminum sheets, plate and bar.

    304, 316 and 17-4PH Stainless Steel sheets, plate and bar.

    A36, 1018, 4130, 4140 516 GR70 Steel sheets, plate and bar.

    Copper and Brass Alloys

    Delrin, FR4, Polycarbonate, Acrylic Sheets and bars.

Material Handling:

Our lifting equipment consists of a 1 TON Jib Crane, three Anver Lifting devices and a 6000 lbs Forklift.

Secondary Operations:

Tapping up to 3/4-10 UNC in Steel, Countersink, Deburring and finishing services are available in-house.

Timesaver up to 18” Wide.

Services Offered by our Business Partners:

Blanchard Grinding up to 42 x 100

Powder coating services

Anodizing Services

Welding Services
